This blow film machine is suitable for making high-density polyethylene (HDPE), low-density polyethylene (LDPE), and linear low-density polyethylene (LLDPE) plastic films, which is widely used in the packaging of household and industrial products such as food, clothing, textiles, and daily necessities.
Video playbackThis machine is currently the most widely used and essential preferred one for blowing film factories in the market.
|
Model |
SS-FM600MM |
SS-FM800MM |
SS-FM1000MM |
SS-FM1200MM |
|
Film Width |
100-600mm |
200-800mm |
300-1000mm |
400-1200mm |
|
Film Thickness |
HDPE:0.005-0.045mm LDPE:0.01-0.1mm |
HDPE:0.005-0.045mm LDPE:0.01-0.1mm |
HDPE:0.005-0.045mm LDPE:0.01-0.1mm |
HDPE:0.005-0.045mm LDPE:0.01-0.1mm |
|
Max Output |
35-40KG/H |
40-45KG/H |
55-60KG/H |
65-70KG/H |
|
Screw Dia |
Φ50mm (38CrMOALA) |
Φ55mm (38CrMOALA) |
Φ60mm (38CrMOALA) |
Φ65mm (38CrMOALA) |
|
Screw Length Ratio |
30:1 |
30:1 |
30:1 |
30:1 |
|
Screw Speed |
10-90rpm |
10-90rpm |
10-90rpm |
10-90rpm |
|
Cooling Fan |
120W × 1 |
250W × 2 |
370W × 2 |
370W × 2 |
|
Main motor |
11KW with inverter |
15KW with inverter |
18.5KW with inverter |
22KW with inverter |
|
Gear Box |
133 |
146 |
173 |
173 |
|
Blower |
1.1KW |
1.5KW |
2.2KW |
2.2KW |
|
Die Head |
HDΦ50mm & LDΦ80mm |
HDΦ80mm & LDΦ150mm |
HDΦ100mm & LDΦ220mm |
HDΦ120mm & LDΦ250mm |
|
Air Ring |
Φ620 |
Φ780 |
Φ780 |
Φ780 |
|
Machine Voltage |
380V 50HZ/220V 60HZ (can be customizable) |
380V 50HZ/220V 60HZ (can be customizable) |
380V 50HZ/220V 60HZ (can be customizable) |
380V 50HZ/220V 60HZ (can be customizable) |
|
Total Power |
30KW |
35KW |
39KW |
48KW |
|
Machine weight |
1.5T |
2.0T |
2.5T |
3.0T |
|
Machine Dimension |
L4.5*W2.0*H3.9m |
L4.5*W2.2*H4.4m |
L5.0*W2.5*H4.8mm |
L5.0*W2.8*H4.8m |
|
Model |
SS-FM1500MM |
SS-FM2000MM |
SS-FM2500MM |
SS-FM3000MM |
|
Film Width |
500-1500mm |
1000-2000mm |
1500-2500mm |
1500-3000mm |
|
Film Thickness |
HDPE:0.005-0.045mm LDPE:0.01-0.1mm |
LDPE:0.01-0.1mm |
LDPE:0.01-0.1mm |
LDPE:0.01-0.1mm |
|
Max Output |
90-110KG/H |
150KG/H |
260KG/H |
300KG/H |
|
Screw Dia |
Φ80mm (38CrMOALA) |
Φ90mm (38CrMOALA) |
Φ110mm (38CrMOALA) |
Φ120mm (38CrMOALA) |
|
Screw Length Ratio |
30:1 |
30:1 |
30:1 |
30:1 |
|
Screw Speed |
10-90rpm |
10-90rpm |
10-90rpm |
10-90rpm |
|
Cooling Fan |
370W × 3 |
550W × 3 |
550W × 4 |
550W × 5 |
|
Main motor |
37KW with inverter |
55KW with inverter |
75KW with inverter |
22KW with inverter |
|
Gear Box |
200 |
225 |
280 |
315 |
|
Blower |
3.0KW |
7.5KW |
11KW |
15KW |
|
Die Head |
HDΦ150mm & LDΦ350mm |
LDΦ500mm |
LDΦ600mm |
LDΦ800mm |
|
Air Ring |
Φ1000 |
Φ1200 |
Φ1400 |
Φ1600 |
|
Machine Voltage |
380V 50HZ/220V 60HZ (can be customizable) |
380V 50HZ/220V 60HZ (can be customizable) |
380V 50HZ/220V 60HZ (can be customizable) |
380V 50HZ/220V 60HZ (can be customizable) |
|
Total Power |
67KW |
115KW |
146KW |
170KW |
|
Machine weight |
4.0T |
10T |
14T |
20T |
|
Machine Dimension |
L6.8*W3.8*H6.5m |
L7.5*W4.0*H7.5m |
L7.5*W4.8*H9.5m |
L8.5*W6.5*H11.0m |
