Single high-speed alloy screw extrusion,This machine is suitable for making high-density polyethylene (HDPE) films, which is widely used in the packaging of household and industrial products such as food, clothing, textiles, and daily necessities.
Video playbackAlso machine can make pearlescent film and biodegradable film through different raw material formulas. This machine is currently the preferred machinery with high cost-effectiveness in the market.
|
Model |
SS-HDHL600MM |
SS-HDHL800MM |
|
Film Width |
100-600mm |
200-800mm |
|
One Layer Film Thickness |
0.005-0.045mm |
0.005-0.045mm |
|
Max Output |
45-50KG/H |
50-60KG/H |
|
Screw Dia |
Φ45mm (metallic) |
Φ50mm (metallic) |
|
Screw Length Ratio |
30:1 |
30:1 |
|
Screw Speed |
10-150rpm(high speed) |
10-150rpm(high speed) |
|
Cooling Fan |
250W × 1 |
250W × 2 |
|
Main motor |
15KW with inverter |
18.5KW with inverter |
|
Gear Box |
146 |
173 |
|
Blower |
2.2KW |
3.0KW |
|
Die Head |
HDΦ50mm(fix die head) |
HDΦ80mm(fix die head) |
|
Air Ring |
Φ700 (double air lip) |
Φ700 (double air lip) |
|
Gusset |
√ |
√ |
|
Winder |
Single winder |
Single winder |
|
Machine Voltage |
380V 50HZ/220V 60HZ (can be customizable) |
380V 50HZ/220V 60HZ (can be customizable) |
|
Total Power |
35KW |
40KW |
|
Machine weight |
2.5T |
3.0T |
|
Machine Dimension |
L4.8*W2.2*H4.5m |
L5.0*W2.4*H4.5m |
